Is machine ka overall design durability par focus karta hai. Proper maintenance ke saath iska service life 7 saal se bhi zyada ho sakta hai, jo traditional machines ke barabar ya kai cases mein usse bhi better hota hai. Transmission system mein cost-effective white belt use kiya gaya hai jo normal working condition mein lagbhag 5 se 6 mahine tak easily chal sakta hai. Isse maintenance cost kam hoti hai aur machine ko bar-bar stop karke parts replace karne ki zarurat bhi kam padti hai.
| item | Specification |
|---|---|
| Product Name | XND 90 high speed wire nail banane ki machine |
| keel ka daayameetar | 2.0 -4.0 mm |
| keel kee lambaee | 34-90 mm |
| aautaput speed | 820 pcs/min max |
| motar paavar | 7.5kw + 3.0 kw |
| saiz | 1540*1380*1430 |
| vazan | 2800 kgs |
XND 90 high speed wire nail banane ki machine ka ek important feature iska automatic lubrication system hai. Conventional machines mein lubrication points zyada hote hain aur operators ko regular manual oiling karni padti hai. Lekin is machine mein lubrication system simplified hai, jisse working area clean rehta hai aur maintenance bhi kaafi convenient ho jata hai.
Production capacity ke mamle mein bhi yeh machine kaafi impressive hai. Standard configuration mein, jaise ki model 2550 setup ke saath, yeh machine ek 8-hour shift mein lagbhag 900 kilogram tak nails produce kar sakti hai. Iska matlab hai ki manufacturers high output achieve kar sakte hain bina additional labor ya extra machines ke. Agar nail size change nahi kiya jata, to mold ko normally teen mahine tak remove karne ki zarurat nahi hoti, jisse downtime kaafi kam ho jata hai.
Precision engineering bhi XND 90 high speed wire nail banane ki machine ki ek khasiyat hai. Machine mein non-contact cutting technology use ki gayi hai jo cutter ki life ko kaafi extend karti hai. Example ke liye, 2.0 mm wire ke saath cutter lagbhag 800 million cuts tak perform kar sakta hai. Mold ki durability bhi kaafi high hai, jo around 50 million cycles tak chal sakta hai, jabki punching components around 25 million operations tak work karte hain. Sabse achhi baat yeh hai ki cutters, molds aur punches ko multiple times refurbish kiya ja sakta hai, jisse long-term production cost kaafi reduce ho jati hai.
Energy consumption ke case mein bhi yeh machine efficient hai. XND 90 high speed wire nail banane ki machine average sirf 3.5KW power use karti hai. Traditional nail machines ke comparison mein yeh lagbhag 20 kWh per ton energy saving provide karti hai. Isse factory ka overall electricity cost kam ho jata hai aur production zyada economical ban jata hai.
Labor efficiency bhi is machine ka ek strong advantage hai. High automation aur stable operation ki wajah se manual involvement lagbhag 60% tak kam ho sakta hai. Machine automatic nail coiling systems aur high-frequency welding machines ke saath bhi achhi compatibility rakhti hai, jisse poori nail production line ko integrate karna aur bhi asaan ho jata hai.
Safety aur product quality ko improve karne ke liye machine mein intelligent sensors bhi install kiye gaye hain. Yeh sensors abnormal conditions detect karke timely alerts provide karte hain. Saath hi integrated wire payoff system 1.4mm se 8mm diameter tak ke wire ko continuous aur stable feeding provide karta hai, jisse production process smooth aur uninterrupted rehta hai.
Compact structure, reliable performance aur high output ke saath XND 90 high speed wire nail banane ki machine un manufacturers ke liye ek ideal solution hai jo large-scale nail production karna chahte hain aur consistent quality maintain karna chahte hain. Yeh machine speed, precision aur operational convenience ka perfect combination provide karti hai.
